| 브랜드 이름: | GENY |
| 모델 번호: | YC-1891D |
| MOQ: | 1pcs |
| 가격: | 협상 가능 |
| 지불 조건: | l/c, t/t, d/p |
| 공급 능력: | 달 당 30 PC |
| Output Current Range | 1mA -120A (Up to 230A Max) |
|---|---|
| Output Current Power | 2000VA (Max) |
| Output Voltage Power | 1000VA (Max) |
| Output Voltage Range | 24V -288V |
| Power Supply | AC220V±10%, 50Hz±2Hz |
|---|---|
| Ambient Temperature | -10°C ... +40°C |
| Ambient Humidity | 35% ... 95% |
| Output Voltage Range | 24V ... 288V |
| Output Voltage Power | 1000VA (Max) |
| Voltage Resolution | 0.01% |
| Voltage Stability | 0.02%/120s |
| Load Change Rate | 0.01% |
| Voltage Distortion | ≤0.3% (Full linear load range) |
| Output Current Range | 1mA ... 120A (Up to 230A Max) |
| Output Current Power | 2000VA (Max) |
| Current Resolution | 0.01% |
| Current Stability | 0.02%/120s |
| Current Distortion | ≤0.3% (Full linear load range) |
| Continuous Current | 100A |
| Phase Adjustment Range | 0° ... 360° |
| Phase Resolution | 0.01° |
| Frequency Adjustment Range | 45Hz ... 65Hz |
| Frequency Resolution | 0.01Hz |
| Power Output Stability | 0.02%/120s |
